FujiFilm GFX 50S User Manual
Page 22
4
1
Bef
o
re
Y
ou
Beg
in
t
HDMI Micro connector (Type D) ..............208
u
Remote release connector (
⌀ 2.5 mm) .....57
v
15 V DC-IN connector .................................... 29
w
Micro USB (Micro-B) USB 3.0/
USB 2.0 connector ..................................57, 213
x
Microphone jack (
⌀ 3.5 mm) .............47, 117
y
Headphone jack ............................................152
z
Battery chamber ............................................. 30
0
Battery latch ..................................................... 31
1
Memory card slot 1 ........................................ 32
2
Memory card slot 2 ........................................ 32
The Cable Protector
A
The cable protector prevents ac-
cidental disconnection of the USB
cable or AC adapter. Attach the pro-
tector as shown and tighten the lock
screw.
B
Connect the cable and pass it through
the protector as shown.
A
B
The Serial Number Plate
Do not remove the serial number plate,
which provides the FCC ID, KC mark, se-
rial number, and other important infor-
mation.
Serial number plate
