326
Editing Registers
Using the Effect menu, you can carry out the following
effect register operations.
• Effect status display
(see page 326)
• Effect attribute settings (see page 326)
• Effect register editing (see page 326)
This section describes the menu for effect registers 1 to 99
as an example.
Carry out similar operations in the User DME Wipe Effect
101-199 menu, User DME Wipe Effect 201-299 menu,
and User DME Wipe Effect 301-399 menu for user
programmable DME registers.
Carry out similar operations in the DEV/PBUS Effect
1-250 menu for P-Bus and Device1 to Device12 registers.
Effect Status Display
The Effect >Effect 1-99 menu displays the following
information.
Region name: The selected region name appears in the
upper part of the list.
Register number
Register name
Write-protected status:
When the register is write-
protected, an “L” appears.
Empty status: When the register is empty, an “E” appears.
Effect Attribute Settings
Applying effect dissolve
Apply the “effect dissolve” attribute to a keyframe effect.
1
Open the Effect >Effect 1-99 >Attribute menu (6221).
2
Press the region display in the upper part of the list to
display a selection window, then select the region in
the selection window.
You can select more than one region.
To select all regions, press [ALL]. To select all
switcher-related regions (M/E, P/P, User), press [SWR
ALL].
3
Press [OK].
4
Select a register.
To select all registers, press [ALL]. To select multiple
registers, set the [Num] parameter.
To select multiple registers with the [Num]
parameter
Specify the register number in the [Register]
parameter, and set the quantity in the [Num]
parameter.
The specified amount of registers is selected from the
specified register number.
5
Press [Effect Dissolve], turning it on.
6
Set the duration.
To set the duration for a temporary attribute
Set the duration for a temporary attribute set in the numeric
keypad control block using the following parameters.
Effect Register Editing
You can carry out the following editing on effect registers
and master timeline registers.
•
Lock: Write-protect the data contents of the register.
• Copy: Copy data between registers.
• Merge: Merge the data of two registers. It is not possible
to merge master timeline registers.
• Move: Move data between registers.
• Swap: Swap the contents of two registers.
• Delete: Delete the data contents of a register.
• Name: Attach a name to a register.
Write-protecting the contents of the effect
register
It is not possible to write-protect an empty register.
1
Open the Effect >Effect 1-99 >Lock menu (6222).
2
Press the region display in the upper part of the list to
display a selection window, then select the region in
the selection window.
You can select more than one region.
To select all regions, press [ALL]. To select all
switcher-related regions (M/E, P/P, User), press [SWR
ALL].
3
Press [OK].
No. Parameter Adjustment
4 Eff Diss
Duration Dissolve duration
No. Parameter Adjustment
5 Temp Dur Temporary attribute dissolve duration
Note
