333
• The banks and number of registers that can be selected
vary depending on the function.
• A register number is not assigned to the bottom left
button of bank 0 by default. You can assign a register
number in the Setup menu.
For details, see “Setting Flexi Pad Control Block Button
Display and Operation” (page 432).
Bank and register selection in the Flexi Pad
control block
Select the bank corresponding to the target register using
the bank selection buttons.
To select bank 0:
Press the [BANK0] button.
To select bank 1:
Press the [BANK1] button.
To select bank 2:
Press the [BANK2] button.
To select bank 0 to 99:
Press the [BANK SEL] button,
and enter the desired bank number (0 to 99) with the
numeric keypad buttons in the memory recall section.
When a bank is selected, the memory recall section
changes to display the register numbers.
The register name is displayed on buttons for registers with
registered data.
The button color varies as follows, according to the
register state.
Gray characters on black:
Register not containing saved
data
White characters on dark blue:
Register containing
saved data
Lit orange:
Last recalled register
You can switch to the register display of the previous or
next bank number using the [PREV BANK] button or
[NEXT BANK] button.
Press the button for the target register to select it, turning it
on orange.
The selected bank and register number are displayed on the
top right button in the memory recall section.
Saving and Recalling Snapshots
This section describes operation of snapshots on M/E-1
bank as an example.
Saving a snapshot
1
In the M/E-1 bank, make the settings for the state you
want to save as a snapshot.
2
In the M/E-1 bank Flexi Pad control block, press the
[SNAPSHOT] button.
This switches the memory recall section to snapshot
operation mode.
The last recalled bank is displayed on the M/E-1 bank.
3
Select the target bank for operation using the bank
selection buttons.
Select from bank 0 to 9 (register number 1 to 99) for
the snapshot.
For details about bank selection, see “Bank and
register selection in the Flexi Pad control block”
(page 333).
4
To add an attribute
, press and hold the
[SNAPSHOT] button, and press the following button
in the memory recall section, turning it on.
In the Flexi Pad control block, it is not possible to add
cross-point hold attributes. When adding attributes,
use the menu
.
5
Still holding down the [SNAPSHOT] button from step
4
, press the save destination register button.
The selected button is lit orange, and the snapshot is
saved.
If you press a button in which a snapshot is already
saved, the existing contents of the register will be
overwritten.
Recalling a snapshot
If a switcher bank region is not assigned to a region
selection button in the numeric keypad control block, the
Flexi Pad control block cannot be used to recall a snapshot.
1
In the M/E-1 bank Flexi Pad control block, press the
[SNAPSHOT] button.
This switches the memory recall section to snapshot
operation mode.
The last recalled bank is displayed on the M/E-1 bank.
Notes
Attribute
Button
Effect dissolve
[EFF DISS] button
Auto transition
[AUTO TRANS] button
Note
Note
Note
