To set these buttons, select a function button and then its behavior, a setting, and
a parameter for that setting.
2
1
3
4
1
Button
2
Behavior
3
Setting
4
Parameter
Function Button Behaves as Preset or Toggle
Once you have selected the function button you want to map, you can select a behavior.
On URSA Mini Pro 12K, URSA Mini Pro 4.6K G2, URSA Mini Pro 4.6K and URSA Mini 4.6K models, you
can also map the HFR button to another behaviour.
The available options are:
Preset
When set to this behavior, pressing a function button will recall a combination of a
setting and a parameter.
To set a preset, select the setting you want to use from the ‘setting’ menu, and adjust
that setting by tapping the arrow icons on either side of the ‘parameter’ menu.
For example, to set the F1 button to recall a preset aperture of f8, select the ‘preset’
behavior, tap the ‘iris’ setting, and tap the arrows on either side of the ‘parameter’ menu
until you get to f8.’ Tapping the preset again returns your camera to the
previous setting.
Up/Down
When set to this behavior, pressing a function button will move a particular setting
up or down.
For example, you may want to set F1 to increase your lens aperture and F2 to decrease
it. To do this, select the ‘F1’ function button, set the behavior to ‘up/down’, and the
parameter to ‘up.’ Do the same for the ‘F2’ function button, but set the option to ‘down.’
Toggle On/Off
When set to this behavior, pressing a function button will toggle a particular setting on
or off. The ‘setting’ menu is disabled in this mode. Instead, tap the left or right
arrows in the parameter menu to scroll through the available options. These are ‘off
speed recording,’ ‘color bars,’ ‘push to talk,’ ‘clean feed,’ ‘display LUT,’ ‘frame guides,’
‘focus assist,’ ‘false color,’ and ‘zebra’. A ‘none’ option is available on URSA Mini
Pro models.
URSA Mini Pro 12K includes a ‘focus zoom’ option. For information on how to use ‘focus
zoom’ when it is enabled on the LCD, see the ‘focus zoom’ section. When ‘focus zoom’
is enabled for your SDI outputs, you can move its region of zoom around using the
‘menu’ wheel and adjust the magnification level using the ‘iris’ wheel.
