Blackmagic Design URSA Mini Pro 12K (PL) User Manual
Page 274
Group
ID
Parameter
Type
Index
Minimum
Maximum
Interpretation
Output
3.0
Overlay enables
uint16
bit field
–
–
–
bit flags:
[0] = display status,
[1] = display frame guides
Some cameras don't allow
separate control of frame
guides and status overlays.
3.1
Frame guides style
(Camera 3.x)
int8
–
0
8
0 = HDTV, 1 = 4:3, 2 = 2.4:1,
3 = 2.39:1, 4 = 2.35:1,
5 = 1.85:1, 6 = thirds
3.2
Frame guides opacity
(Camera 3.x)
fixed16
–
0.1
1.0
0.0 = transparent, 1.0 = opaque
3.3
Overlays
(replaces .1 and .2
above from
Cameras 4.0)
int8
[0] = frame guides
style
–
–
0 = off, 1 = 2.4:1, 2 = 2.39:1,
3 = 2.35:1, 4 = 1.85:1, 5 = 16:9,
6 = 14:9, 7 = 4:3, 8 = 2:1,
9 = 4:5, 10 = 1:1
[1] = frame guide
opacity
0
100
0 = transparent, 100 = opaque
[2] = safe area
percentage
0
100
percentage of full frame
used by safe area guide
(0 means off)
[3] = grid style
–
–
bit flags:
[0] = display thirds,
[1] = display cross hairs,
[2] = display center dot,
[3] = display horizon
Display
4.0
Brightness
fixed16
–
0.0
1.0
0.0 = minimum, 1.0 = maximum
4.1
Exposure and focus tools
int16
bit field
0x1 = zebra,
0x2 = focus assist,
0x4 = false color
–
–
0 = disable, 1 = enable
4.2
Zebra level
fixed16
–
0.0
1.0
0.0 = minimum, 1.0 = maximum
4.3
Peaking level
fixed16
–
0.0
1.0
0.0 = minimum, 1.0 = maximum
4.4
Color bar enable
int8
–
0
30
0 = disable bars,
1-30 = enable bars with timeout
(seconds)
4.5
Focus Assist
int8
[0] = focus assist
method
–
–
0 = Peak,
1 = Colored lines
[1] = focus line color
–
–
0 = Red,
1 = Green,
2 = Blue,
3 = White,
4 = Black
4.6
Program return feed enable int8
–
0
30
0 = disable, 1-30 = enable with
timeout (seconds)
Tally
5.0
Tally brightness
fixed16
–
0.0
1.0
Sets the tally front and tally rear
brightness to the same level.
0.0 = minimum,
1.0 = maximum
5.1
Front tally brightness
fixed16
–
0.0
1.0
Sets the tally front brightness.
0.0 = minimum,
1.0 = maximum
5.2
Rear tally brightness
fixed16
–
0.0
1.0
Sets the tally rear brightness.
0.0 = minimum,
1.0 = maximum
Tally rear brightness cannot be
turned off
274
Developer Information
