Blackmagic URSA Mini Pro EF Mount
Blackmagic URSA Mini Pro EF Mount supports an extensive range of EF stills and
cinema lenses.
The EF mount kit includes:
1 x EF mount
The EF mount lets you attach common EF stills lenses.
1 x Shim set
The shim set includes the following thicknesses:
0.50mm
0.30mm
0.20mm 0.18mm
0.15mm
0.12mm 0.10mm
0.05mm
0.025mm
1 x Baffle tool
The baffle in the EF mount is not removable, however we have
included a baffle tool in the EF kit as a spare item you can use if
you also have the PL mount.
4 x 2mm Hex M3 x 18mm mount screws
The four M3 x 18mm Hex screws are used in the EF and
F mount so it is best to keep the screws together with the
respective mount.
The EF mount kit also comes with a full spare sets of
screws in case the originals are misplaced.
Tools Required
When attaching the EF mount, you will need a 2mm Hex driver. While it’s not absolutely
required, we recommend using a torque wrench able to accurately set a maximum torque
of 0.45Nm to reduce the potential of over tightening the screws.
2mm Hex driver
217 Interchangeable Lens Mount
