Contacting Dell

|

67

Pin assignments

RS232

Pin description

RS232

1

2

TXD

2

3

RXD

3

4
5

GROUND

5

6

7

Not Used

7

8

Not Used

8

9

RS232 protocol communication settings

Connection settings

Value

Baud Rate

9600 bps

Data Bits

8 bits

Parity

None

Stop Bits

1 bit

Flow control

None
