14
Names and functions of parts (remote control)
When the main unit and the remote control both have buttons
with the same functions, this manual explains how to use one of
the buttons. The other corresponding button can be used in the
same manner.
a STANDBY/ON button
Press to put the unit into standby mode or turn it on.
b Input selection buttons
Use to select the playback source.
o The LINE button has no function.
c
INFO button
Press to show information, including upconversion (page 16).
d
UPCONVERT button
Press to change the upconversion setting.
e
FILTER button
Press to change the filter setting.
This changes the filter for PCM input.
f MUTE button
Press to minimize the volume.
g DIMMER button
Press to adjust the brightness of the main unit’s display.
h HEADPHONE button
Press to turn headphone output on and off.
When headphone output is turned off, sound is output from
the analog audio output (LINE OUT) connectors.
i
DISPLAY button
j MENU button
Press to enter setting mode (page 21).
Press when in setting mode to return to the previous screen.
k
Up/down ( k / j ) buttons
Use to select setting items.
l
ENTER button
Press to confirm the selected item.
m VOLUME (+/−) buttons
Use to adjust the volume.
e
d
c
a
f
b
g
h
j
l
m
i
k
