EN
23
Line output level
Use to select audio level output from the analog audio output (LINE
OUT) connectors.
MENU
LINE OUT LEVEL
VARIABLE
FIXED 0dB
A maximum of 2 Vrms is output. Select this if you want to adjust
the volume using an amplifier.
o No sound will be output if headphones are connected.
FIXED +6dB
A maximum of 4 Vrms is output. Select this if you want to adjust
the volume using an amplifier.
o No sound will be output if headphones are connected.
o If the sound distorts, set this to FIXED 0dB.
VARIABLE
This will enable adjustment of the analog output level using the
VOLUME knob. Select this if you want to adjust the volume using
this unit.
o No sound will be output if headphones are connected.
OFF
No sound is ever output.
Display brightness
MENU
DIMMER
SLIGHTLY BRIGHT
DARK
Dark
SLIGHTLY BRIGHT
Lit dimly
BRIGHT
Lit brightly
AUTO OFF
Unlit automatically
o The display stays unlit even when the unit is on.
Volume display
This sets how the volume is shown.
MENU
VOLUME TYPE
STEP (0-100)
STEP (0-100)
This shows the volume in steps from 0 (minimum) to 100
(maximum).
dB
This shows the volume in decibels (dB).
Screen indication
Select the information shown to the right of the playback source.
MENU
DISPLAY TYPE
VOLUME
VOLUME
The volume will be shown.
SAMPLING FREQ.
Information about the playback source will be shown.
