EN
15
Display
When on
Z
c
NT-505-X
NETWORK PLAYER
After the above messages appear, the input source will be shown on
the display.
Playback source information
The playback source information display will appear after turning
the unit on as well as after about 7 seconds pass without operation
when a setting screen is open.
The input signal format or volume is shown to the right of the playback
source. Press the DISPLAY button on the remote control to change
what is shown.
Display example
Playback source information displayed
Stopped
USB
CHECK
Playback source
Shown when the connection is being checked
Playing back
USB
PCM
44.1k
Input signal format
Sampling frequency
Press the DISPLAY button on the remote control.
Volume display
USB
−45.5
dB
Volume
Playback source name
This shows the name of the selected source.
The names on the display correspond to the selected connectors as
follows.
The names in parentheses appear when switching.
USB (USB)
USB port on the back of the unit
COAX1 (COAXIAL 1)
RCA COAXIAL digital audio input connector on the back of the
unit
COAX2 (COAXIAL 2)
Coaxial connection with the digital audio input (OPT/COAX IN)
on the front of the unit
OPT1 (OPTICAL 1)
OPTICAL digital audio input connector on the back of the unit
OPT2 (OPTICAL 2)
Optical connection with the digital audio input (OPT/COAX IN)
on the front of the unit
NET (NETWORK)
ETHERNET port
Bluetooth (Bluetooth)
Bluetooth device
Input signal status
This shows the input source signal status.
CHECK
The connection is being checked.
PCM 32kHz
PCM 44.1kHz
PCM 48kHz
PCM 88.2kHz
PCM 96kHz
PCM 128kHz
PCM 176.4kHz
PCM 192kHz
PCM 256kHz
PCM 352.8kHz
PCM 384kHz
PCM 705.6kHz
PCM 768kHz
DSD 2.8MHz
DSD 5.6MHz
DSD 11.2MHz
DSD 22.5MHz
These show the input signal type and sampling frequency.
