**See the TEAC HR Streamer User’s Manual for details about USB flash drives
and networks.
***This input connector can be used for both optical and coaxial connections.
Bluetooth function
Bluetooth version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.2
Output class . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Class 2
(transmission distance without obstructions**** . . . . . . . . . . . . . . 10 m)
Supported profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A2DP, AVRCP
Supported A2DP codecs . . . . . . . . SBC, AAC, Qualcomm® aptX™ audio,
Qualcomm® aptX™ HD audio, LDAC
Supported A2DP content protection . . . . . . . . . . . . . . . . . . . . . . . . .SCMS-T
Maximum number of stored pairings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
****The transmission distance is approximate. The transmission distance
could vary depending on the surrounding environment and electromag-
netic waves.
Clock sync input
Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BNC
Input sampling frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 MHz
Input impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Ω
Input level . . . . . . . . . . . . . . . . . .Rectangle wave: equivalent to TTL levels
Sine wave: 0.5 to 1.0 Vrms
General
Power supply
Model for Europe . . . . . . . . . . . . . . . . . . . . . . . . AC 220–240 V, 50/60 Hz
Model for U.S.A./Canada . . . . . . . . . . . . . . . . . . . . . . . . . AC 120 V, 60 Hz
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 W
Standby power . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.4 W (in standby mode)
External dimensions (W × H × D including protrusions)
290 mm × 84.5 mm × 248.7 mm
(11 1/2 " Ч 3 3/8 " Ч 9 7/8 " )
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.1 kg (9 1/8 lb)
Operating temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +5°C to +35°C
Operating humidity range . . . . . . . . . . . . 5% to 85% (no condensation)
Storage temperature range . . . . . . . . . . . . . . . . . . . . . . . . . −20°C to +55°C
Included accessories
Power cord × 1
RCA conversion (RCA to mini plug) cable × 1
Remote control (RC-1330) × 1
Batteries for remote control (AAA) × 2
Pads × 3
Owner’s manual (this document, including warranty) × 1
o For information about the warranty, users living in the USA and
Canada should see pages 86–87 and the back cover (warranty
document). Users living in Europe and other regions should see
page 87.
o The TEAC HR Streamer User’s Manual can be downloaded from
the TEAC International Site (https://teac.jp/int/).
o Design and specifications are subject to change without notice.
o Weight and dimensions are approximate.
o Illustrations in this manual might differ slightly from production
models.
Analog audio outputs
Connectors
XLR connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pair (L/R)
RCA connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pair (L/R)
Output impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . XLR: 188 Ω
RCA: 150 Ω
Maximum output level (1 kHz/full-scale, into 10 kΩ)
FIXED 0dB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . XLR/RCA: 2.0 Vrms
FIXED +6dB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . XLR/RCA: 4.0 Vrms
VARIABLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . XLR: 12 Vrms
RCA: 6 Vrms
Frequency response* . . . . . . . . . . . . . . . . . . 5 Hz – 80 kHz (+1 dB/−5 dB)
S/N ratio* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110 dB (A-Weight, 1 kHz)
Distortion* . . . . . . . . . . . . . . . . . . . . 0.0015% (1 kHz, LPF: 20 Hz – 20 kHz)
*Measurement conditions
Input signal: 192kH 24-bit PCM
Measurement output: RCA
PCM digital filter: ON
Headphones output
Connector . . . . . . . . . . . . . . . . . . . . . . . 3.5mm 4-pole stereo mini jack × 1
Maximum effective output . . . . . . . . . . 500 mW + 500 mW (into 32 Ω)
Compatible impedance range . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16–600 Ω
Digital audio inputs**
COAXIAL digital . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA connector × 1
3.5mm mini jack*** × 1
(3.5mm mini plug connection also possible using RCA-mini plug
adapter cable)
(0.5 Vp-p, 75 Ω)
OPTICAL digital . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Square connector × 1
Round connector*** × 1
(−24.0 to −14.5dBm peak)
USB flash drive . . . . . . . . . . . . . . . . . . . . . . . . . . . USB Type A port (front) × 1
(USB 2.0 compliant)
USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . USB Type B port (rear) × 1
(USB 2.0 compliant)
LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1000BASE-T
PCM data sampling frequency
COAXIAL digital
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
OPTICAL digital
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
USB . . . . . . . 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz,
352.8 kHz, 384 kHz, 705.6 kHz, 768 kHz
USB flash drive/Network
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz,
352.8 kHz, 384 kHz
Quantization bit depth
COAXIAL digital/OPTICAL digital . . . . . . . . . . . . . . . . . . . . . . . . 16/24-bit
USB/USB flash drive/Network . . . . . . . . . . . . . . . . . . . . . . . 16/24/32-bit
DSD data sampling frequency
COAXIAL digital/OPTICAL digital . . . . . . . . . . . . . . . . . . . . . . . . . 2.8 MHz
(supported using 176.4kHz/24-bit DoP transmission)
USB . . . . . . . . . . . . . . . . . . . . . . . 2.8 MHz, 5.6 MHz, 11.2 MHz, 22.5 MHz
USB flash drive/Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.8/5.6 MHz
Specifications
