StreamLIVE™ PRO User Manual
6
7 HDMI 2 audio
source Switches to the HDMI 2 audio source.
The button is lit when switched to this source.
8 HDMI 3 audio
source Switches to the HDMI 3 audio source.
The button is lit when switched to this source.
9 HDMI 4 audio
source Switches to the HDMI 4 audio source.
The button is lit when switched to this source.
10 AFV Audio-Follows-Video: Press to light the AFV button. the
source’s audio is played whenever its video is being
displayed.
11 mute Mutes / unmutes the audio of the audio source selected.
Muting HDMI source 1, 2, 3, or 4, will also turn off its AFV.
12 PGM Switches to the audio of PGM.
The button is lit when switched to this source.
Video Section (controls the video settings of the system)
13 scenes selector Selects the current stream (PGM) scene and the preview
(PRV) scene.
Greenly lit button indicates PRV Preview.
Redly lit button indicates PGM Preview.
Transition Control Section (switches the current stream (PGM) scene to the preview
(PRV) stream and vice versa)
14 auto (transition) Pressing the Auto button performs the transition at a set
interval (0.3 - 3 seconds).
Go to the Setting Deck and refer to page 52 on how to
modify this specified time.
Press and hold for 3 seconds to enter Quick Mode . Refer
to Edit the video scenes in scene editor, tune audio
settings in the audio mixer deck, adjusting audio delays
in the settings deck, etc. Tap Apply to apply the changes.
on page 70 for more information.
15 cut (transition) The transition happens immediately when you press the
Cut button.
Press and hold for 3 seconds to enter Quick Mode . Refer
to Edit the video scenes in scene editor, tune audio
settings in the audio mixer deck, adjusting audio delays
in the settings deck, etc. Tap Apply to apply the changes.
on page 70 for more information.
No. Component Description
