StreamLIVE™ PRO User Manual
36
2 PGM
Preview The program scene, or the on-air video output of the system.
You can tap on the bottom right-hand corner or tap on the
scene twice to view the video source in full screen mode. An
example is shown below:
Tap the icon on the top left-hand corner or tap the
scene twice to return to the previous page.
3 Volume
Control Tap and drag the volume slider to adjust PGM and earphone
volume.
4 Scene
Selector 8 scenes are shown here.
Green outline scene = PRV Preview.
e.g.
Red outline scene = PGM Preview.
e.g.
Tap a scene to put the scene into the PRV Preview section.
Tap and hold a scene to re-order the scene sequence.
To put the scene in PRV Preview to PGM Preview, use the
Transition Control (explained below).
No. Component Description
