StreamLIVE™ PRO User Manual
40
4 Media Select the source(s) and how the source(s) are laid out for
the scene.
1. HDMI-A: Display an input source between HDMI 1,
HDMI 2, HDMI 3, and HDMI 4 input sources.
2. HDMI-B: Display an input source between HDMI 1,
HDMI 2, HDMI 3, and HDMI 4 input sources.
3. Dual View: Dual View Mode (Picture-in-Picture or
Picture-by-Picture).
4. Background: Plain Background.
5 Add Text
Overlay Tap this icon to add a text overlay. Refer to Add/Edit Text
Overlay on page 44 below for more information.
To edit the location and size of the overlay, select the
overlay in the “Overlay” region and configure in the “Scene
Display” region.
The added overlay will appear in the “Overlay” region.
Up to 30 text overlays (layers) are support per scene.
6 Add Image
Overlay Tap this icon to add an image overlay.
Tapping allows you to add an Image Overlay. iPad will
flip to the Photos page for you to select an image. Select
the image and tap OK.
To relocate, tap and hold the overlay to drag.
To resize, refer to
Resize/Crop Tool on page 42.
The added overlay will appear in the “Overlay” region.
Up to 5 image overlays (layers) are support per scene.
7 Switch Video
Source (Dual-
View) During dual-view, tapping this button switches video source
position between 1 and 2.
No. Component Description
