NETGEAR Nighthawk AX8 8 Stream Wi-Fi 6 DOCSIS 3.1 Cable Modem and Multi-Gigabit Router - Manual (Page 135)

Table 5. Factory default settings (Continued)
Enabled WiFi communication WiFi
See the modem
router label SSID name
WPA2-PSK (AES) Security
Enabled Broadcast SSID
United States Country/region WiFi (continued)
Auto 1 RF channel (2.4 GHz)
CH 153 (or manually
select channels) RF channel (5 GHz)
Up to 1200 Mbps at
2.4 GHz, 4800 Mbps
at 5 GHz Operating mode
1
Maximum WiFi signal rate derived from IEEE Standard 802.11 specifications. Actual throughput can vary. Network
conditions and environmental factors, including volume of network traffic, building materials and construction, and
network overhead, lower actual data throughput rate.
Technical Specifications
Table 6. Modem router specifications
Description Feature
TCP/IP, DHCP, Dynamic DNS, UPnP, and SMB Data and routing protocols
120V, 60 Hz, input
19V/3.16A DC output Power adapter (North America)
10.4 x 8.5 x 4.3 in (264 x 215 x 110 mm) Dimensions
2.55 lb (1.16 kg) Weight
0° to 40° C (32º to 104º F) Operating temperature
90% maximum relative humidity, noncondensing Operating humidity
FCC Part 15 Class B Electromagnetic emissions
10BASE-T, or 100BASE-TX, or 1000BASE-T, or 2.5GBASE-T
RJ-45 LAN
User Manual 135 Supplemental Information
Nighthawk AX8 AX6000 WiFI Cable Modem Router Model CAX80
