Change the appearance of the map
display by repeatedly pressing the
arrow button in the upper left
corner of the screen. It toggles
between three different map modes;
Heading up, North up, and 3D.
Heading up (2D map) always
shows the direction of forward
travel to be upward on the screen.
This view is available for map scales
up to 2.5 miles (4 kilometers). For
larger map scales, this setting is remembered, but the map is
shown in North up only. If the scale returns below this level,
then Heading up is restored.
North up (2D map) always shows the northern direction to be
upward on the screen.
3D map mode provides an elevated perspective of the map. This
viewing angle can be adjusted and the map can be rotated 180
degrees by dragging your finger along the shaded bar with arrows
at the bottom of the map.
Re-centering the map can be done by pressing this icon
whenever you scroll the map away from your vehicle’s current
location.
Auto Zoom
Press the green bar to access map mode, then select the + or - zoom
button to bring up the zoom level and Auto buttons on the touchscreen.
When the Auto button is pressed, Auto Zoom is turned on and Auto is
displayed in the bottom left corner of the screen. The map zoom level
then synchronizes with vehicle speed. The slower the vehicle is traveling,
the farther in the map is zoomed in; the faster the vehicle is traveling,
the farther the map is zoomed out. To turn the feature off, just press the
+ or - button again.
Map Icons
Vehicle mark shows the current location of the vehicle. It stays
in the center of the map display, except when in scroll mode.
