DVR User Manual
57
8
Mobile Surveillance
This DVR supports mobile surveillance by iPhone, Gphone
,Blackberry or smart phones with
Windows mobile OS. At the same time, it supports 3G network. We tested Dopod D600
(WM5) and Dopod S1 (WM6), which work fine with the DVR.
If you want to make mobile surveillance, please enable network service on the DVR first and
refer to Chapter 4.6 Network configuration. The below is the use instructions on mobile client
end for four OS.
8.1 By Phones with Windows Mobile OS
Step 1
:Activate the network access on mobile phone.
Step 2: Run “Internet Explorer” and input the server‟s address. The connection is built up
shown as below picture on the left.
Step 3
:Click on the software name. A dialog box pops up as below picture in the middle.
Step 4
:Click “Yes” to start downloading and installing.
Step 5
:PCam will be opened automatically after installation. Refer to the picture on the right.
Step 6
:Input the server‟s address, ID and password respectively in the columns of “Server”,
“User” and “Password”, and click “Go” to log on the server. Refer to the below picture on the
left:
Step 7
:Camera 1 is the default channel after login. Change the channel in rolling-down menu
of “Channel”. Refer to the below picture on the right.
