Appendix B Calculate Recording Capacity
Users can calculate the size of hard disk according to the saving time and DVR recording
settings. The DVR uses fixed video bit rate. The below are the details at different settings.
Resolu
tion
Frame
Rate
Totally(FPS)
Video
Quality
Bit Rate
(kbps)
Used Space
(MB/h)
WD1
30
Highest
2.5M
1125
Higher
2M
900
Medium
1.75M
788
Low
1.5M
675
Lower
1M
450
Lowest
768
338
D1
25
Highest
2M
915
Higher
1.5M
712
Medium
1M
468
Low
768K
297
Lower
512K
241
Lowest
256K
112
The calculation format is: Total Recording capacity =Used space per hour (MB/h)
(coverage rate of hard disk) × recording time (hour) ×channel numbers
For instance, one customer uses PAL cameras, set resolution to WD1, video quality to Lowest,
frame rate to 25 fps for enabling total 4 channels. He wants the unit to record continuously in
a month. Below is the calculation:
Total Recoding capacity =338 (mb/h) X 24(hours/day) X30(days) X4(channels)=
973440
(MB) ≈950 (GB)
Therefore, customers just install one SATA HDDs with 1TB, it can almost record for one
month.
