Rev. 1.08 - 25 -
SRP-500
7. Self Test
The self test lets you know if your printer is operating properly.
It checks the control circuits, printer mechanisms, print quality, ROM version, and DIP
switch settings.
The test is independent of any other equipment or software, so it is a good idea to run it
when you first set up the printer or if you have any trouble. If the self test works correctly,
the problem is in the other equipment or the software, not the printer.
7-1 Make sure the printer is turned off and the printer cover is closed properly.
7-2 While holding down the Feed button, turn on the printer and continue to hold until the
paper begins to feed. The self test prints the printer settings and cuts the paper and
pauses. (The power light blinks.).
7-3 Press the Feed button to continue printing the rolling ASCII pattern. Repeat for the
nozzle pattern, NV bit image(s).
7-4 The self test mode terminates after printing NV bit image(s) automatically.
