48
D*AP LM 4
Technical data - optional interface modules – pin assignment
4x analog I/O [AN 144]
4x AES I/O [DD 188]
8x analog out [AN 108]
connector :
4 x analog I/O
female
25-pin Sub-D
1
OUT-4 +
2
GND
3
OUT-3 -
4
OUT-2 +
5
GND
6
OUT-1 -
7
IN-4 +
8
GND
9
IN-3 -
10
IN-2 +
11
GND
12
IN-1 -
13
14
OUT-4 -
15
OUT-3 +
16
GND
17
OUT-2 -
18
Out-1 +
19
GND
20
IN-4 -
21
IN-3 +
22
GND
23
IN-2 -
24
IN-1 +
25
GND
connector :
AES I/O
female
25-pin Sub-D
1
OUT-4 +
2
GND
3
OUT-3 -
4
OUT-2 +
5
GND
6
OUT-1 -
7
IN-4 +
8
GND
9
IN-3 -
10
IN-2 +
11
GND
12
IN-1 -
13
14
OUT-4 -
15
OUT-3 +
16
GND
17
OUT-2 -
18
OUT-1 +
19
GND
20
IN-4 -
21
IN-3 +
22
GND
23
IN-2 -
24
IN-1 +
25
GND
connector :
8 x analog out
female
25-pin Sub-D
1
OUT-8 +
2
GND
3
OUT-7 -
4
OUT-6 +
5
GND
6
OUT-5 -
7
OUT-4 +
8
GND
9
OUT-3 -
10
OUT-2 +
11
GND
12
OUT-1 -
13
14
OUT-8 -
15
OUT-7 +
16
GND
17
OUT-6 -
18
OUT-5 +
19
GND
20
OUT-4 -
21
OUT-3 +
22
GND
23
OUT-2 -
24
OUT-1 +
25
GND
