SLR™ Quick-Lock™ Butterfly Bracket
The Quick-Lock Butterfly Bracket is used to attach 2 x Point Series cabinets in a horizontal array.
The Quick-Lock™ Butterfly Bracket is designed to fly vertically but can be tilted in the vertical
plane. Both cabinets can then be rotated independently of each other in the horizontal plane.
There is a Quick-Lock™ Pin on both arms of the butterfly bracket to allow each box to be
snapped into place separately.
(Part # 8 - 920111, 12 - 920114, 15 - 920118)
3.6
Parts and Terminology
