The Side Lock Revolver (SLR™) rigging system promotes flexibility in
setup even in the most Dali-esque venues with difficult coverage
areas. The series enclosures have been designed to fully integrate
with one another. The Point 8’s height matches the Point 115 Sub’s
width for easy, underhang applications. All cabinets use discreet
SLR™sockets placed on 4 sides of the enclosure, availble for use
with all Point series rigging methods offered. Many of the SLR™
rigging parts feature a ‘Quick-lock™’ mechanism for a one-step
installation and/ or angle adjustment.
Built-in Rigging Features:
2 Sets of SLR™ Sockets
Built-in Polemount Socket
4 x 5/16 -18 threads for Omni Mount 30 Series
Optional Rigging Parts:
SLR™ Quick-Lock™ Components:
Vertical & Horizontal Bracket™, Butterfly Bracket™,
Articulator™
SLR™ Components:
Sight Mount Bracket™, Extended Sight Mount Bracket™, Super
Sight Mount Bracket™
SLR™ Underhang Components:
Point 115 Sub to Point 8 Horizontal Bracket (Left & Right)
Point 15 to Point 8 Horizontal Bracket (Left & Right)
SLR™ Polemount Components:
Polemount Base™ for Quick-Lock™ Horizontal Brackets™
SLR™ C-Clamp Components:
Quick-Lock™ 360° Articulator™, Fixed Base™
SLR™ Monitor Mode Components:
Wedger™
* please refer to the Point Series user
manual for details on all SLR™ rigging
systems and parts.
Dimensions & Weight
Height Front (cm) 17.3/4” (45.1)
Width (cm) 9.7/8” (25.1)
Depth (cm) 9.7/8” (25.1)
Weight (Kg) 23.6 lbs (10.7)
Weight (Kg) with Crossover 27.6 lbs (12.5)
Box Shape Anisometric Hexagon
Box Finish
Hardware Finish Textured Water Borne Acrylic
Polyester Sandtex™ Powder
Protective grille 18 Gauge steel & foam
Horn Configuration Fiberglass Waveguide
Cabinet Construction Rugged 11 ply 5/8” Baltic Birch
Options 1,114 Pantone colours
Frequency Response (+/-3dB)
Full Range Preset 65Hz - 20kHz
Frequency Range
with Xover Preset 135Hz - 20kHz
Maximum SPL
(Xover Preset: High Pass @80Hz) (Continuous / Peak)
Passive with Full Range Preset 118.6dB / 124.6dB
Passive with Xover Preset 121.4dB / 127.4dB
Active with Full Range Preset n/a
Active with Xover Preset n/a
Directivity
Horizontal 90° / 60°
Vertical 60° / 90°
Sensitivity (2.83V @ 1m)
LF 93.64 dB
HF 103.82 dB
LF/MF Section (Impedance Ω) 8” ND-8LM Kevlar Neodymium
Mid-Bass driver (16Ω)
HF Section (Impedance Ω) 1.7” B&C DE 500 1” exit
compression driver (16Ω)
Power Handling (AES / Program / Peak)
LF 250 /500 /1000
HF 50 / 100 / 200
Connection 2 x Neutrik Speakon™ NL4
connectors
Specifications are subject to change without notice.
technical specifications
Adamson Systems Engineering
1401 Scugog Line 6, Port Perry,
ON L9L 1B2, Canada
t: [905] 982 0520 f: [905] 982 0609
www.adamsonsystems.com
[email protected]
