The Point 15
T
he Point 15 is the largest 2 way cabinet in the Point Series range. The Point 15’s frequency
range (+/-3dB) is 55Hz -18kHz (full range) or 90Hz -18kHz (with xover preset). Common uses are
live bands, DJs or high level program material. The Point 15 is available with a rotatable 40° x
20°, 40° x 60° or 60° x 90° wave guide with a 3” B&C DE800 16Ω 1.4” exit compression driver
and features the 15” ND-15L 6Ω Neodymium / Kevlar Mid Bass Driver. It comes complete with
SLR™ rigging sockets, a built in pole mount socket and is Omnimount (60 Series) ready . It is
available in active or passive version. Presets are available for the Point Controller Digital Signal
Processor.
The Point 12
The Point 12 is the second largest 2 way cabinet in the Point Series range. The Point 12’s
frequency range (+/-3dB) is 60Hz-18kHz (full range) or 110Hz-18kHz (with xover preset). It is
the most versatile of the Point Series range and can be used for speech systems, live bands,
DJs or high level program material where the low mid response of the powerful Point 15 is
not required. The Point 12 is available with a rotatable 40° x 20°, 40° x 60° or 60° x 90° wave
guide with a 3” B&C DE800 16Ω 1.4” exit compression driver and features the 12” ND-12 6Ω
Neodymium / Kevlar Mid Bass Driver. It comes complete with SLR™ rigging sockets, a built in
pole mount socket and is Omnimount (60 Series) ready . It is available in active or passive
version. Presets are available for the Point Control Digital Signal Processor.
1.2
The Point Series Range
The Point 8
The Point 8 is the smallest 2 way cabinet in the Point Series range. The Point 8’s frequency
range (+/-3dB is 65Hz - 20kHz) (full range) or 135Hz-20kHz (with xover preset). The Point 8 can
be used for speech systems and program material or anywhere where high power without
an excessive amount of low frequency energy is required in a small footprint. The Point 8 is
available with a rotatable 60° x 90° wave guide with a 1.7” B&C DE500 16Ω 1” exit compression
driver and features the 8” ND-8 16Ω Neodymium / Kevlar Mid Bass Driver. It comes complete
with SLR™ rigging sockets, a built in pole mount socket and is Omnimount (30 Series) ready . It
is available in active or passive version. It can be used in passive mode with the Point 115 Sub
run from a single amp channel where extra low frequency output is required. The Point 8 box
geometry allows it to be used horizontally under a vertically flown Point 15 or Point 115 Sub as
a down fill cabinet. Presets are available for the Point Control Digital Signal Processor.
