18
PROGRAMMER'S GUIDE FOR v02.00.46
3.2.3 Detailed commands sequence

Set the recalling filter : This command allows including or
excluding preset elements from recalling.
Syntax : <filter value> PMcat
L
F
The <filter value> can be calculated by adding the values
associated with each element to include (not filtered elements).
Allowed values are from 0 up to 2047.
Note that adding all elements gives the value 2047, that means
“include all elements”, no filtering occurs.
Example 1 : 2047PMcat
L
F
recall all elements.
Example 2 : 2046PMcat
L
F
recall all elements except layers
sources.

Set scale enable : This command allows automatic resizing of layers due to changes in screen size. (for
example due to covering size change)
Syntax : <value> PMlse
L
F
<value> can be 0 to disable or 1 to enable resizing.

Set the origin memory number : This command sets the memory number to recall.
Syntax : <value> PMmet
L
F
The <value> is the Web RCS memory number minus 1, allowed values are
from 0 up to 143.

Set the destination screen number :
Syntax : <value> PMscf
L
F
The <value> is the Web RCS screen number minus 1, allowed values
are from 0 up to 7, depending on machine and configuration.

Set the Program/Preview destination value :
Syntax : <value> PMprf
L
F
The destination <value> is 0 for Program or 1 for Preview.

Start the copy : Once all previous parameters are set, start the copy process.
Syntax : 1PMloa
L
F
Only value 1 is allowed, machine will immediately acknowledge the command,
then will answer the same command with the 0 value after the end of the copy.

Wait the end of the copy : This step is optional. End of copy is signaled by answering the PMloa
command with value 0. This answer cannot arrive later than a few 1/10s.
Answer : PMloa0
C
R
L
F
Wait this answer for a few 1/10s max.
element to recall value
layers sources 1
layers positions and sizes 2
layers transparencies 4
layers cropping parameters 8
layers borders 16
layers transitions 32
layers effects 64
layers timings 128
speed parameters 256
not used 512
native background parameters 1024
