Avalon Firestyles 864 See-Thru GS2 Installation - Manual (Page 20)

20 Installation
(for qualified installers only)
© Travis Industries 4141208 100-01404
Electrical Connection (required)
 The electrical line to the grounded receptacle inside the fireplace must be installed by a qualified installer and
must meet all local codes.
 Make sure the household breaker is shut off prior to working on any electrical lines.
 The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of
local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1.
 The electrical line must be a min. 14 gauge, and supply 120 Volts at 60 Hz (2 Amps).
Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and
dangerous operation.
a b c d
