S E T T I N G S U P P L Y O P T I O N S
4
This chapter explains how to select the supply type, ribbon, speed,
feed mode, backfeed, print position, supply position, margin
position, cut position, dispense position, backfeed distance,
separators, skip index mode, set knife control, and the error
action. This chapter also explains how to adjust the print contrast.
The options are listed in the table below.
Option Choices Default
Supply Type Aperture/Die Cut/Black
Mark/Continuous Die Cut
Ribbon No/Yes/High Energy Yes
Speed 2.5/4.0/6.0/8.0/10.0/Default Default
Feed Mode Continuous/On-Demand Continuous
Backfeed Off/On/Extended Off
Print Position -450 to 450 0
Supply Position -300 to 300 0
Margin Position -99 to 99 0
Cut Position -300 to 300 0
Dispense Position 50 to 200 65
Backfeed Distance 10 to 200 65
Separators No/Yes/Long No
Skip Index No/Yes No
Knife Control -20 to 20 0
Error Action Normal or Ostrk/Cont 1x to 5x Normal
Contrast -699 to 699 0
SUPPLY CONTRAST NETWORK
PORT
SETTINGS
MAIN MENU
CANCEL
ALL
PRINT
MODE REPEAT
BATCH
SETUP DIAG.
BATCH
ENTRY BATCH
OPTIONS
FL ASH
MEMORY
SCRIPTS
SUPPLY
TYPE
RIBBON SPEED
FEED
MODE
BACKFEED POSITIONING SEPARATORS SKIP INDEX
VERIFIER RFID DEFAULTS
KNIFE CTRL
ERROR
ACTION
Setting Supply Options 4-1
