21
2
Hardware Installation
1 GNDC1 56 PEG_RX1-
2 IDE_D7 57 NC
3 IDE_D6 58 PEG_RX2+
4 IDE_D3 59 PEG_RX2-
5 IDE_D15 60 GNDC7
6 IDE_D8 61 PEG_RX3+
7 IDE_D9 62 PEG_RX3-
8 IDE_D2 63 NC
9 IDE_D13 64 NC
10 IDE_D1 65 PEG_RX4+
11 GNDC2 66 PEG_RX4-
12 IDE_D14 67 NC
13 IDE_IORDY 68 PEG_RX5+
14 IDE_IOR# 69 PEG_RX5-
15 PCI_PME# 70 GNDC8
16 PCI_GNT2# 71 PEG_RX6+
17 PCI_REQ2# 72 PEG_RX6-
18 PCI_GNT1# 73 SDVO_DATA
19 PCI_REQ1# 74 PEG_RX7+
20 PCI_GNT0# 75 PEG_RX7-
21 GNDC3 76 GNDC9
22 PCI_REQ0# 77 NC
23 PCI_RESET# 78 PEG_RX8+
24 PCI_AD0 79 PEG_RX8-
25 PCI_AD2 80 GNDC10
26 PCI_AD4 81 PEG_RX9+
27 PCI_AD6 82 PEG_RX9-
28 PCI_AD8 83 NC
29 PCI_AD10 84 GNDC11
30 PCI_AD12 85 PEG_RX10+
31 GNDC4 86 PEG_RX10-
32 PCI_AD14 87 GNDC12
33 PCI_C/BE1# 88 PEG_RX11+
34 PCI_PERR# 89 PEG_RX11-
35 PCI_LOCK# 90 GNDC13
36 PCI_DEVSEL# 91 PEG_RX12+
37 PCI_IRDY# 92 PEG_RX12-
38 PCI_C/BE2# 93 GNDC14
39 PCI_AD17 94 PEG_RX13+
40 PCI_AD19 95 PEG_RX13-
41 GNDC5 96 GNDC15
42 PCI_AD21 97 NC
43 PCI_AD23 98 PEG_RX14+
44 PCI_C/BE3# 99 PEG_RX14-
45 PCI_AD25 100 GNDC16
46 PCI_AD27 101 PEG_RX15+
47 PCI_AD29 102 PEG_RX15-
48 PCI_AD31 103 GNDC17
49 PCI_IRQA# 104 VCC_12VC1
50 PCI_IRQB# 105 VCC_12VC2
51 GNDC6 106 VCC_12VC3
52 PEG_RX0+ 107 VCC_12VC4
53 PEG_RX0- 108 VCC_12VC5
54 NC 109 VCC_12VC6
55 PEG_RX1+ 110 GNDC18
Row C
