www.dfi .com Chapter 4 BIOS Setup
45
Chapter 4
i217 LAN Controller
Enable or disable onboard NIC.
Wake on LAN
Set this field to enable to wake up the system via the onboard LAN or via a LAN card
that supports the remote wake up function.
High Precision Timer
Enable or disable the High Precision Event Timer.
Restore AC Power Loss
Power-off
When power returns after an AC power failure, the system’s power is off. You must
press the Power button to power-on the system.
Power-on
When power returns after an AC power failure, the system will automatically power-on.
Last State
When power returns after an AC power failure, the system will return to the state
where you left off before power failure occurs. If the system’s power is off when AC
power failure occurs, it will remain off when power returns. If the system’s power is
on when AC power failure occurs, the system will power-on when power returns.
PCI Express Confi guration
settings.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Intel PCH RC Version
Intel PCH SKU Name
Intel PCH Rev ID
 PCI Express Confi guration
 USB Confi guration
 PCH Azalia Confi guration
i217 LAN Controller
Wake on LAN
High Precision Event Timer Confi guration
High Precision Timer
Restore AC Power Loss
0.9.0.0
QM87
02/B0
[Enabled]
[Disabled]
[Enabled]
[Power On]
Chipset
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save and Reset
ESC: Exit
PCH-IO Configuration
This section configures PCH parameters.
PCI Express Configuration
PCI Express Root Port 1
Settings.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
PCI Express Confi guration
 PCI Express Root Port 1
 PCI Express Root Port 2
 PCI Express Root Port 3
 PCI Express Root Port 4
 PCI Express Root Port 5
 PCI Express Root Port 6
 PCI Express Root Port 7
PCIE Port 8 is assigned to LAN
Chipset
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save and Reset
ESC: Exit
PCI Express Root Port 1 to PCI Express Root Port 7
Control the PCI Express Root Port.
PCI Express Root Port 1
Settings.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
PCI Express Root Port 1
ASPM Support
 PME SCI
Hot Plug
PCIe Speed
Chipset
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save and Reset
ESC: Exit
[Enabled]
[Disabled]
[Enabled]
[Disabled]
[Gen1]
ASPM Support
Select the ASPM level. The options are listed as below:
Force L0s Forces all links to L0s State.
Auto The BIOS automatically select an ASPM level.
Disabled Disables ASPM.
