CNA-8000 Installation and Configuration
707158-003 5-9
Deleting Token Ring Drops
When pressing the Delete button on the Configure Token Ring Drops panel, a new panel
will be displayed with the currently configured Drops listed. An example of what this
panel looks like is displayed below.
Select one or more of the listed drops then press the Delete button.
Button Descriptions
Return: Pressing this button will return you to the Configure Token Ring Drops panel.
Select All: When pressing the Select All button, all of the displayed Drops will get
selected.
Clear All: Pressing the Clear All button will deselect any selected Drops.
Delete: Pressing the Delete button will cause a message to display:
You are about to delete the selected drops on line 0. Are you sure you want to do this?
Pressing the OK button will complete the deletion. Pressing the Cancel button will abort
the deletion.
