LDK 8000 User’s Guide | Menu structure and contents
6-9
Safe area
On, Off
The safe area indicates an area that represents
80% of the whole viewfinder picture area.
0
Op.
Safe area type
16:9, 15:9, 14:9, 4:3
Set the aspect ratio of the safe area marker.
0
Op.
Marker
On, Off
Turn on to show the used area limits.
0
Op.
Marker type
15:9, 14:9, 4:3
Set the aspect ratio of the used area marker.
0
Op.
Marker style
Dot, Shad, Both
Set the style of the used area marker.
0
Op.
Marker shading
Shad, Black
Set the shading of the used area marker.
0
Op.
Ind. White
0..99 (70)
Adjust the contrast of the characters.
2
Op.
Ind. Black
0..99 (30)
Adjust the black shading of the characters; 0 =
black, 99 = no shading.
2
Op.
Display
On, Time (reset on power
up)
Select the menu display to be on all the time or
to disappear after a set time.
2
Op.
Menu Time
0..10 (10)
Set the length of time the menu is displayed
when set to Time.
3
Op.
Info Time
0..20 (5)
Set the length of time that pop-up messages
are displayed.
3
Op.
Rotary speed
0..10 (5)
Adjust the sensitivity of the rotary control
wheel.
3
Op.
EXT AspectRatio
4:3, 16:9
Aspect ratio converter for external video
displayed in VF.
0
LOC AspectRatio
4:3, 16:9
Aspect ratio when the SD 5-inch viewfinder is
used (only with modification).
0
MENU
VALUES
DESCRIPTION
LEVEL
FILE
