HEIDENHAIN iTNC 530 109
4.4 Cr
eating and W
riting Pr
ogr
a
ms
Looking for the same words in different blocks
For this function, set the AUTO DRAW soft key to OFF.
To select a word in a block, press the arrow keys
repeatedly until the highlight is on the desired word.
Select a block with the arrow keys.
The word that is highlighted in the new block is the same as the one
you selected previously.
Finding any text
8 To select the search function, press the FIND soft key. The TNC
displays the dialog prompt Find text:
8 Enter the text that you wish to find.
8 To find the text, press the EXECUTE soft key.
If you have started a search in a very long program, the
TNC shows a progress display window. You then have the
option of canceling the search via soft key.
In the tool axis the TNC always captures the coordinates
of the tool tip and thus always takes the active tool length
compensation into account.
