50
Connection panels
The connection panels on your television
allow you to connect signal input cables
as well as a variety of extra equipment,
such as a video recorder or DVD.
The equipment you connect to these
sockets must be registered in the
CONNECTIONS menu. For further
information, refer to the chapter
‘Register additional video equipment’ on
page 28.
Standard sockets
~
(Mains supply)
Connection to the mains supply.
HDMI-IN (A–B)
HDMI™ (High Definition Multimedia Interface)
sockets for connection of an HDMI video source
or a PC. Sources connected to these sockets can
be registered to any of the AV sockets. Supported
formats are:
Video: 480i, 480p, 576i, 576p, 720p, 1080i,
1080p.
PC: 640 x 480, 800 x 600, 1024 x 768 .
SPDIF (1–2)
Digital audio input sockets for connection of
external equipment.
PUC (1–4)
For IR control signal to external equipment
(connected to the AV sockets).
AV (1–2)
21­pin sockets for connection of additional video
equipment, such as a DVD player, set­top box, a
decoder or video recorder.
AV 3 (Pr, Pb, Y and R, L, VIDEO)
For connection of video signals from an external
source such as an HDTV source. Can be used in
conjunction with the 21­pin AV sockets – or a
digital audio socket.
VGA
For connection of a PC for reception of analogue
graphics. Supports the following resolutions:
60 Hz; 640 x 480, 800 x 600, 1024 x 768, 1280 x
720.
AERIAL
Aerial input socket for an analogue TV signal, such
as an external aerial or cable TV network.
DVB
Aerial input socket for a digital TV signal.
System Module sockets
AV 4
21­pin sockets for connection of additional video
equipment. If you have a Bang & Olufsen recorder,
we recommend that you connect it to this socket.
MASTER LINK
Socket for connection of a compatible Bang &
Olufsen audio system. The socket is also used for
BeoLink distribution of sound throughout the
house.
RF OUT
Aerial output socket for distribution of video
signals to other rooms. Requires an RF Link
Amplifier also.
