IWL3000 series 25
© ads-tec GmbH • Raiffeisenstr.14 • 70771 Leinfelden-Echterdingen
6.4 Calling up the device web interface
To access and open the device web interface, start up your web browser. In the browser’s address bar,
enter the following IP address and then confirm with Enter:
http://192.168.0.254
Login
Once the IP address has been entered with success, the login prompt appears. The default settings are
to be entered in the login prompt.
The default configuration on delivery is:
User name :
admin
Password : admin
Confirm your entries by clicking on OK
Fig. 12:
Information:
If the login prompt does not appear, check to ensure that the device has been
connected via a RJ45 connection cable. Otherwise, connect the device to a PC
(Device LAN connection <> PC LAN connection).
If there is still no connection to the firewall login screen, check the proxy and local
firewall settings. Often, local subnet addresses (e.g. 192.168.x.x) are also diverted
to a proxy server. In this case, it is possible to select the "Bypass proxy server for
local addresses" option to enter the address in question.
