Modular Block System: Hydraulic Presses
Standard Function Blocks
MS1
MS2
MAct
NO_1
NO_2
TS12
TOPD
TMut
TInt
2xTOPD
SMd2=0
MP1
Sequential muting cycle
Output parameter
MAct switches off
before the interrupt
time
(TInt) elapses, if
no further muting
signals are present
(i.e. includes MP1/
MP2).
SB072
