392
4-3. Do-it-yourself maintenance
Checking and replacing fuses
If any of the electrical components do not operate, a fuse may have
blown. If this happens, check and replace the fuses as necessary.
Vehicles without smart key system: Turn the engine switch
off.
Vehicles with smart key system: Turn the “ENGINE START
STOP” switch off.
The fuses are located in the following places. To check the
fuses, follow the instructions below.
Open the fuse box cover.
Engine compartment
Type A: Push the tab in and lift
the lid off.
Type B: Push the tab in and lift
the lid off.
STEP 1
STEP 2
STEP 3
