Page 425
401
4-3. Do-it-yourself maintenance
4
Mainten
ance an
d ca
re
9
ACC
7.5 A
Audio system, power outlets,
power rear view mirror control,
automatic transmission shift lock
system, main body ECU, clock,
smart key system
10
MIR HTR
10 A
Outside rear view mirror defoggers
11
PWR OUTLET
15 A
Power outlet
12
RR FOG
10 A
No circuit
13
IGN
7.5 A
Multiport fuel injection system/
sequential multiport fuel injection
system, steering lock system, front
passenger occupant classification
system, smart key system, SRS
airbag system
14
GAUGE 2
7.5 A
Gauges and meters
15
S-HTR
15 A
Seat heaters
16
FR WIP
25 A
Windshield wipers
17
RR WIP
15 A
Rear window wiper
18
WSH
15 A
Windshield washer, rear window
washer
19
ECU IG 1
10 A
Electric cooling fan, ABS, TRAC,
VSC, AUTO LSD function, downhill
assist control system, hill-start
assist control system, Active
Torque Control 4WD system, auto-
matic transmission shift lock sys-
tem, air conditioning system, main
body ECU, electric moon roof,
stop/tail lights, electric power steer-
ing system, clock, AC inverter, auto
anti-glare inside rear view mirror
20
ECU IG 2
10 A
Air conditioning system, rear win-
dow defogger, emergency flashers
Fuse
Ampere
Circuit
