TOYOTA 2011 Rav4 User Manual
Page 421
397
4-3. Do-it-yourself maintenance
4
Mainten
ance an
d ca
re
8
ECU-B
10 A
Gauges and meters, clock, main
body ECU, wireless remote control,
smart key system, audio system,
front passenger occupant classifi-
cation system, ABS, TRAC, VSC,
AUTO LSD, downhill assist control
system, hill-start assist control sys-
tem, Active Torque Control 4WD
system
9
DOME
10 A
Vanity lights, personal/interior
lights, interior light, luggage com-
partment light, engine switch light,
foot lights
10
H-LP LH
10 A
Left-hand headlight (high beam)
11
H-LP RH
10 A
Right-hand headlight (high beam)
12
H-LP LL
10 A
Left-hand headlight (low beam)
13
H-LP RL
10 A
Right-hand headlight (low beam)
14
AC INV
15 A
AC inverter
15
TOWING*
1
30 A
No circuit
16
DEICER
20 A
Windshield wiper deicer
17
HTR
50 A
Air conditioning system
18
PTC NO.3
50 A
No circuit
19
PTC NO.2
50 A
No circuit
20
PTC NO.1
50 A
No circuit
21
HEAD MAIN
50 A
H-LP LH, H-LP RH, H-LP LL,
H-LP RL fuses
22
RDI*
2
30 A
Electric cooling fan
FAN 2*
1
50 A
Fuse
Ampere
Circuit
