Xtramus NuApps-IGMP-RM V1.2 - Manual (Page 5)

1. General Description of NuApps-IGMP-RM
NuApps-IGMP-RM is the professional testing software for Internet Group Management
Protocol (IGMP), a communication protocol designed to manage the membership of
Internet Protocol multicast groups. IGMP establishes multicast group memberships by
connecting IP hosts and adjacent multicast routers. It will be an important protocol when multicast-enabled
applications such as webinars, Internet radio/TV, and video/audio conferences are now being used widely
over the Internet. From those applications used widely, how to test the equipment becomes an important
issue.
NuApps-IGMP-RM must be activated with NuStreams Chassis. NuApps-IGMP-RM is designed for Xtramus
Technologies XM-RM series module cards. The table down below contains the XM-RM module cards,
FPGA/Firmware versions that are supported by NuApps-IGMP-RM.
Module Cards Support NuApps-IGMP-RM
Module Card FPGA Version Firmware Version
XM-RM661/671/681 V3.1b034 v1.6b106
XM-RM751/761/781 V4.0b004 v1.6b106
XM-RM731 V3.0b000 v1.6b161
XM-RM881 v1.4b008 V0.9b026
XM-RM881-2 v1.4b008 V0.1b028
XM-RM891 v1.4b008 V1.6b106
＊ Note: NuStreams-2000i and NuStreams-600i are required as well.
Also, please make sure that your PC meets the requirements listed in the table down below before
installing NuApps-IGMP-RM.
OS Windows XP Windows Vista/7
RAM 512MB RAM 1GB RAM
CPU Pentium 1.3Ghz or higher
HDD 10 GB Available Space
＊ Note: Large amount of data will be generated while running NuApps-IGMP-RM. It is
recommended to preserve enough available Hard-Disk space to store these data.
5
