Page 110
User Manual
Lx / Ls Series
106
7.8 Replaceable Parts
In order to ensure prompt, accurate service, please provide the following information, when
applicable for each replacement part ordered.
a. Model number and serial number of the instrument.
b. Argantix part number for the sub-assembly where the component is located. (California
Instruments PART #)
c. Component reference designator if applicable (REF #)
d. Component description.
e. Component manufacturers (VENDOR)
All replaceable part orders should be addressed to:
California Instruments Corporation.
Attention: Customer Service
9689 Towne Centre Drive
San Diego, California 92121-1964
United States of America
Orders may also be placed using the following fax number: 1 858 677 0904 or via email:
[email protected]
REF #
Sub
CI PART #
DESCRIPTION
MNF, P/N
QTY
Common Assemblies
A1-2,3
4009-456-4
Heatsink assembly (Amplifier)
CI
3
A1
5001-725-2
Amplifier Power board
CI
1
A2
7004-702-1
Amplifier Control board
CI
1
A5
7004-700-1
Power Mother board
CI
1
F1,2,3
270176
Fuse, 20A / 250V
Bussmann, ABC20
3
A6
7004-705-1
Control Mother board
CI
1
A8
4009-737-1
EMI board, 208V & 400V
CI
1
A9
7004-703-1
Current Limit board
CI
1
A12
7004-716-1
Range Relay board
CI
1
A13
7004-704-1
System Interface board
CI
1
A18
7004-401-1
Controller Assembly, Single Phase
CI
1
A18
7004-401-3
Controller Assembly, Three Phase
CI
1
A19
4009-737-3
EMI board, 400V
CI
1
A1
7004-715-1
Controller Board
CI
1
A2
7004-709-1
Keyboard / Display board
CI
1
B1
241182
Fan, 4" 24 VDC
Rotron, MD24B2
Nidec, B31257-10
EBM, 4292H
1
B2
241183
Fan, 6" 24 VDC
Rotron, JQ24B4
NMB, 5920PL-05W-
1
