User Manual Lx / Ls Series
133
10.4 Power Group Reference
The following power groups are supported by the –704F option.
Test Group Description
704F_TP_SAC Single phase, AC mode, 400 Hz nominal frequency
704F_TP_SVF Single phase, AC mode, variable nominal frequency
704F_TP_SXF Single phase, AC mode, 60 Hz nominal frequency
704F_TP_TAC Three phase, AC mode, 400 Hz nominal frequency
704F_TP_TVF Three phase, AC mode, variable nominal frequency
Table 10-1: DO160 Test Groups
10.5 Available Tests
Available tests at the Group level are shown in this section. For details on test levels and test
times for various test conditions in each group, refer to section 10.7 in this manual.
10.5.1 Normal Operation
AC Mode:
Test Section
Steady State Limits for Voltage and Frequency (Includes Unbalance) 102
Voltage Phase Difference 103
Voltage Modulation 104
Frequency Modulation 105
Total Voltage Distortion 107
Normal Voltage Transient 109
Normal Frequency Transient 110
10.5.2 Transfer Operation
AC Mode:
Test Section
Power Interrupt 201
