4.2.14 LIMIT Menu
The Limit menu displays the maximum available value for voltage, frequency and current range
of the power supply. This screen is used for information only and contains no user changeable
fields. The limit values shown cannot be changed.
ENTRY DESCRIPTION
LIM LVOLT Low Voltage
Range Displays maximum available output voltage in
the low voltage range.
HVOLT High Voltage
Range Displays maximum available output voltage in
the high voltage range.
LIM LFREQ Low Frequency
Limit Displays minimum available output frequency.
HFREQ High Frequency
Limit Displays maximum available output frequency
CURR C range Displays maximum available current in low
voltage range and single phase mode. If only 2
or 3 phase mode is available, this value is the
maximum available current per phase.
PHASE (C) Phase Setting Displays phase angle for phase C. Valid values
are 120 for three phase or mode configuration,
0 for single phase only configuration. Any other
value indicates split (2) phase configuration.
