Serial Port3 Type:
COM3 Options: [RS232 Type] or [RS485 Type]
[RS232 Type] for RS232 Mode
[RS485 Type] for RS485 or RS422 Mode
WatchDog Setting:
[Disable]
Options: [10sec,20sec,30sec,40sec,1min,2min,4min]
3.4.4 Hardware Health Configuration
BIOS SETUP UTILITY
Advanced
Hardware Health Configuration
Fan configuration mode
setting
← Select Screen
↑↓ Select Item
+- Charge Field
F1 General Help
F10 Save and Exit
ESC Exit
CPU Temperature :41℃/105℉
CPUFAN Speed :4800 RPM
CPUFAN Mode Setting [Manual
Mode ]
CPUFAN PWM Control [250 ]
V02.68 © Copyright 1985-2009 American Mega trends , Inc.
CPU Temperature:
Show you the current CPU temperature.
CPUFAN Speed:
Show you the current CPU Fan operating speed.
CPUFAN Mode Setting:
[Manual Mode]
[Thermal Cruise Mode]
[Speed Cruise Mode]
[Smart Fan3 Mode]
