XPA200-7984-I-OPT1, X-Band SSPA Remote Control Remote Control
XPA200-7984-I-OPT1, Rev.2 5-14
5.8.3.5 Alarm Status
Alarm Status: <DEV/RAS_'cr'
Confirmation: >DEV/RAS_'cr'
+28_xx'cr' +28 VDC Fault
+12_xx'cr' +12 VDC Fault
-12_xx'cr' -12 VDC Fault
+5_xx'cr' +5 VDC Fault
-5_xx'cr' -5 VDC Fault
+10_1_xx'cr' +10 PS#1 Fault
+10_2_xx'cr' +10 PS#2 Fault
TEMP_xx'cr' Temperature Fault
FAN1_xx’cr’ Fan 1 Fault
FAN2_xx’cr’’lf’] Fan 2 Fault
xx = OK or FT
5.8.3.6 Summary Alarm Status
Summary alarm is set to Fault (FT) if any of the items in
paragraph 5.8.4.5 are faulted.
Summary Alarm: <DEV/SAS_'cr' xx = OK or FT
Confirmation: >DEV/SAS_xx'cr''lf']
5.8.3.7 Terminal Status Change
The TSC_ command can be used to determine if the status of
the terminal has changed since it was last polled. If any of the
parameters listed in the RCS or RUS commands have changed as a
result of user operations or if any new fault condition occur the
TSC_ command will return YES. The TSC_ command will then
continue to return YES until any of the following commands are
received: RCS_, RUS_, RAS_, PACRCS_, PACRUS_, or PACRAS.
Configuration Status: <DEV/TSC_'cr'
Confirmation: >DEV/TSC_nnn'cr''lf'] nnn = YES/NO
