Diet Manager
D3651US-D 5
To Add an Ingredient to the Recipe,
click on the Add Ingredient button.
This will display the Add New
Ingredient to Recipe screen.
To add an Ingredient, Click on the
Down Arrow in the Code /
Description box. This will display a
drop-down menu selection of all the ingredients entered in the Ingredient screen. Select the ingredient from
the list. Enter the amount to load under either the Actual Wt./Head or Dry Wt./Head depending on your
selection made under the Build By selection.
Motion Weight – This setting prevents the ingredient or corral to advance if the weight is unstable or
moving. The motion weight is the amount of weight the display changes by for the “Motion” Arrow to
begin flashing. This allows the "Motion Weight Value" to be adjusted for each feedline. The indicator
uses the motion weight value to determine when the weight on the scale is changing rapidly. Motion
detection will activate when the weight displayed has moved more than "Motion Weight" (ex. 20lbs) in less
than "2 seconds".
This is different than the standard motion detection which activates when the weight displayed has moved
more than "2 display counts" in less than "2 seconds". The standard motion detection is selected whenever
the indicator is first turned ON or the "Motion Weight" value is set to "0". The "Motion Weight Value" has
a range from 000(OFF) to 999. The weight value is either lb or kg depending on setting for Display Units in
Long Form Setup.
To access this option: Enter short cut number 103 and press the [Select] key. Press [Select] key to toggle
on/off. Press the [On] key to save.
Tolerance Weight – This option is useful if you need to set different tolerance weights for individual
ingredients. The tolerance weight determines when the delay timer will begin. For example: if your
tolerance weight is 100 lbs/Kgs on corn silage, when you reach 100 remaining to load the “delay time” will
begin to count down.
This tolerance weight will over ride the tolerance set at the indicator for only ingredients that have a
tolerance weight entered from the software.
The auto-advance resets the "delay time" counter every time the weight moves out of the tolerance window.
If enabled, "motion detection" also resets the "delay time" counter
Modify Ingredient - To modify an ingredient select the ingredient and click on Modify Ingredient.
Delete Ingredient – To delete an ingredient select the ingredient and click on Delete Ingredient.
Change Ingredient Order – To change the ingredient order, select the ingredient and click on Move Up or
Move Down.
When complete, click Ok to save the ingredient. Repeat as required to enter the ingredients for the Recipe.
Moving to Other Recipes – To move between different recipes, click the Next and Previous buttons.
Enter/Update Corrals
Add New Corrals
Select the Corrals tab, or
from the Main Menu, select
Files, Corrals. Click New
to add a Corral.
Enter the Corral Data:
