18 DR
®
POWERWAGON-PRO
RAISE BED
(DUMP)
LOWER BED
Figure 31
Electric Dump System - Optional
The Electric Dump System brings new conveniences to the function of your DR POWERWAGON-PRO.
We have included some operating hints and precautions. Please review them carefully.
Operating the Electric Dump
1. Set the Parking Brake.
2. Remove the Front Panel.
3. Hold Power Dump Switch in the upper position, RAISE BED (DUMP) to raise the Bed (Figure 31).
4. Hold Power Dump Switch down in the lower position, LOWER BED to lower the Bed.
Operating Hints
•
The Electric Dump System allows the Bed to be stopped and positioned anywhere in the tipping range.
Emptying loose material and depositing solid loads in a more precise way.
•
The Electric Dump System also makes it possible to distribute loose materials over an area rather
than in a concentrated pile for distribution later. With the Bed partially tipped, you can move your
DR
POWERWAGON-PRO in reverse while the material flows from the front of the Bed. This is
especially helpful in road maintenance and similar work.
•
Make certain you are familiar with the terrain where you intend to work and anticipate the effect that
load changes in the Dump Bed might have upon operating factors. Review your Safety
& Operating
Instructions Manual carefully for safe procedures.
•
EVEN DISTRIBUTION OF BED LOADS REMAINS AN IMPORTANT FACTOR IN THE OPERATION
OF THIS EQUIPMENT.
•
CHANGING THE LOCATION AND/OR QUANTITY OF THE LOAD IN THE DUMP BED WILL AFFECT
THE HANDLING PROPERTIES OF THE MACHINE.
•
ALWAYS SET THE PARKING BRAKE WHEN YOUR MACHINE IS STOPPED. BE ALERT TO CHILDREN
AND ADULTS IN THE AREA WHEN YOU ARE RUNNING THE MACHINE.
