22 DR
®
POWERWAGON-PRO
Lubrication
WHEN PERFORMING ANY MAINTENANCE, YOU MUST FIRST SHUT OFF THE ENGINE, SET THE
PARKING BRAKE, WAIT FIVE (5) MINUTES TO ALLOW PARTS TO COOL AND DISCONNECT THE SPARK
PLUG WIRE, KEEPING IT AWAY FROM THE SPARK PLUG.
Your DR POWERWAGON-PRO was lubricated at the Factory. The transmission is factory sealed and
lubricated for life with 16 ounces of 90-weight gear oil. The operator needs only to provide engine
lubrication, wheel and cable lubrication.
Supplies Needed:
•
SAE 30 Oil
•
#2 Lithium Grease
1. There are two (2) Grease Fittings on the Swivel Wheel:
one (1) at the top front of the Wheel Bracket, and one
(1) toward the center of the Wheel
(Figure 11). Grease
these two (2) Fittings with #2 lithium grease to keep the
Wheel spinning freely at least every 25 hours of
operation per the Maintenance Checklist on page 19.
2. Using SAE 30 Oil, lubricate the Parking Brake Lever and
Cable at the Operator's end, and the Throttle Lever and
Cable (Figures 12 and 13) at both ends. Operate the
Levers to work lubricant into the Cables.
3. Lubricate the Key Switch (Figure 6 on page 13) with SAE
30 Oil .
Figure 12
Throttle
(Lubricate both
ends)
Brake (Lubricate this
end only)
Figure 11
Grease
Fittings
Figure 13
Engine End of the
Throttle Cable
