Models 397-00x, 396-00x, 398-00x, 397-00xxx, 398-00xxx, and 392-001
Construction
Panel ..................................................................................... 14-gauge, type 304 brushed stainless steel
Back box ....................................................... 16-gauge cold-rolled steel with black polyurethane finish
Dial Pad (Models 398-00x and 392-001 only) .......................................................... Chrome-plated zinc
Dimensions
Front panel .......................................................................... 12.00 H  10.00 W inches (305  254 mm)
Back box (overall) ...................................... 10.06 H  8.43 W  2.50 D inches (256  214  63.5 mm)
Cutout for mounting back box .............................................. 10.13 H  7.63 W inches (257  194 mm)
Weight
Model
397-00x ............................................................................................................... 6.5 lbs. (2.9 kg)
Model 396-00x ............................................................................................................... 6.5 lbs. (2.9 kg)
Model 398-00x ............................................................................................................... 7.2 lbs. (3.3 kg)
Model 392-001 ............................................................................................................... 7.2 lbs. (3.3 kg)
Code Blue Retrofit Phones
Dimensions .............................................................. 11.75
 8.50  2.68 inches (298.5  215.9  68.1 mm)
Weight
Model
397-00xCB .......................................................................................................... 6.0 lbs. (2.7 kg)
Model 398-00xCB .......................................................................................................... 6.7 lbs. (3.0 kg)
Ramtel Retrofit Phones
Dimensions .............................................................. 11.88
 8.25  2.68 inches (301.6  209.6  68.1 mm)
Weight
Model
397-00xRT .......................................................................................................... 6.0 lbs. (2.7 kg)
Model 398-00xRT .......................................................................................................... 6.7 lbs. (3.0 kg)
Talk-A-Phone Retrofit Phones
Dimensions ................................................................ 11.75
 9.5  3.20 inches (298.5  241.3  81.3 mm)
Weight
Model
397-00xTP ........................................................................................................... 6.0 lbs. (2.7 kg)
Model 398-00xTP ........................................................................................................... 6.7 lbs. (3.0 kg)
Approval Standards
Safety of Information Technology Equipment ..................................................................... UL/CSA 60950
Enclosures for Electrical Equipment ................................................................................................ Type 3R
47 CFR Part 68
Certification Number .......................................................................................... US: ADGTE05BGTC2010
Ringer Equivalence Number ..................................................................................................................... .5B
Network connection (USOC) ................................................................................................................. RJ11
IC Information (Canada)
IC Certification Number ...................................................................................................... 822B-GTC2010
Ringer Equivalence Number ..................................................................................................................... .5B
Connection Method ............................................................................................................................ CA11A
