Auto-Dial Telephones Manual
Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains
sensitive business and technical information that is confidential and proprietary to GAI-Tronics. GAI-
Tronics retains all intellectual property and other rights in or to the information contained herein, and
such information may only be used in connection with the operation of your GAI-Tronics product or
system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any
third party.
Product Overview
Telephones
RED ALERT ® series Auto-dial (AD series) Telephones have been designed for maximum environmental
sustainability and high audio quality. The AD series telephones provide reliable, hands-free, two-way
communications in nearly any environment as all models are rated Type 3R. The AD series products are
intended for a single-button call activation telephone in a non-emergency environment.
Each AD series telephone complies with the Americans with Disabilities Act (ADA) in both physical and
operational characteristics. Each telephone includes a Braille label for vision-impaired individuals for
identifying the “call” function of the telephone and a visual CALL
RECEIVED WHEN LIT LED for
hearing-impaired individuals. The LED will flash when the CALL button is pressed (call in progress) and
will provide a steady illumination when the call has been answered. The LED will remain illuminated
until the call has been terminated.
The CALL button on each telephone can be programmed to dial three different telephone numbers. These
include a primary telephone number and two “rollover” telephone numbers. In the event that the first
number goes unanswered or is busy, the telephone will automatically dial the first rollover number. The
second rollover number will be dialed if the first rollover number cannot connect. This feature is
completely programmable.
All RED ALERT ® Auto-dial series Telephones are line-powered and can be connected to any of the
following networks:
 Central Office (C.O.) line to the Public Switched Telephone Network (PSTN)
 24 V dc or 48 V dc analog station port of a Private Branch Exchange (PBX), Private Automatic
Branch Exchange (PABX), or Key Service Unit (KSU).
N OTE : Connection to pay telephone extensions or shared service (party) lines should be avoided.
