GAI-Tronics VoIP Basic Programming Guide - Manual (Page 10)

Pub. 42004-481B
VoIP Telephone Basic Programming Guide Page 9 of 28
f:\standard ioms - current release\42004 instr. manuals\42004-481b.doc
10/13
Table 3. Unit Settings Parameters needed for basic configuration
Parameter Function
HOST NAME Sets the unit host name and consists of a maximum 15 alpha-numeric
characters (a–z, A–Z, 0–9). The host name identifies the unit on the network,
and is also used in email and syslog messages to identify the source of the
message. If using DHCP, this field must be kept unique for each telephone
on the system.
Default value: A unique string starting with “GT” and followed by the serial
number of the main circuit board inside the telephone (referred to as the
“Board serial” on the home page).
DEFAULT_ANS_MODE
Sets the default answer mode. This mode will be used to answer a call when
ANSMODE1, ANSMODE2 and PAGEMODE are not triggered.
Values available are RING, PICK-UP, PAGE and STEALTH.
RING is normal telephone operation, where a button must be pressed or
handset lifted to answer an incoming call.
PICK-UP is intercom auto-answer mode, where the telephone auto-answers
and provides normal duplex audio, preceded by an announcement tone.
PAGE is where the unit auto-answers and disables the microphone. A
“splash” tone (tone 9) is emitted from the speaker to alert those nearby of an
impending page announcement. The output level of the speaker is increased
to its maximum level.
STEALTH is where the telephone provides no indication of the incoming call
and immediately auto-answers the call. The speaker is muted, and the
microphone gain is enhanced.
Default value: PICK-UP is set as the factory default.
