Reference
Typical Gas Train Layout 400 - 800 MBH
High Gas
Pressure Switch
(optional)
Low Gas
Pressure Switch
(optional)
Manual Pilot
Shut-off Valve
Pilot
Regulator
Pilot
Solenoid
Burner Gas
Pressure
Test Port
Burner Differential
Pressure Sensor
Pilot Gas Pressure
Test Port
Burner Manual
Shut-off Valve
Modulating
Valve
Safety Shut-off
Valves
Regulator
R - 1
Figure 30.
400-800 MBH Gas Train
